XA Series 120-160HP
0102030405
Product parameters
| Model | XA1404 | ||
| Dimension (L*W*H) | mm | 4600*2300*2950 | |
| Min. operating weight | kg | 4490 | |
| Wheelbase | mm | 2300 | |
| Wheel track (front/rear) | mm | 1750、1850、1950、2050/1620-2100 | |
| Engine | Model | / | YTO140HP |
| Type | / | Vertical, water-cooled, four-stroke | |
| Qty of cylinders | Cylinder | 6 | |
| Rated power | HP/KW | 140HQ/103KW | |
| Rated speed | r/min | 2200 | |
| Gearbox | / | TDF16+8 | |
| Gear shift type | / | shift sleeve | |
| Steering | Steering type | / | Full hydraulic steering |
| Brake | Brake type | / | Hydraulic brake, wet type, disc type |
| Walking device | Tire size (front/rear) | / | 12.4-24/16.9-34 |
| Working device | Suspension device type | / | Rear, 3-point suspension, type 2 |
| Suspension device category | / | Category II | |
| Tillage Depth Adjustment | / | Height adjustment, float control | |
| Hydraulic output device | Group | 2 | |
| Standard PTO speed | r/min | keys540/1000 | |
Product advantages
1.Equipped with a 140 hp six-cylinder engine, providing strong power and high efficiency.
2.16+8 gears ensure smooth shifting and are suitable for various agricultural operations.
3.Fully hydraulic steering and wet braking offer easy handling and reliable braking safety.
4.Standard dual hydraulic output and Class II suspension ensure strong compatibility with agricultural implements.
5.Moderate wheelbase and adjustable track make it suitable for both paddy and dry land, providing stable passability.
6.A rational overall layout and sufficient weight ensure smooth and slip-free operation.
