Product parameters
| Model | XA1204 | ||
| Dimension (L*W*H) | mm | 4600*2200*2950 | |
| Min. operating weight | kg | 4220 | |
| Wheelbase | mm | 2240 | |
| Wheel track (front/rear) | mm | 1440-1740/1610-2210 | |
| Engine | Model | / | YTO120HP |
| Type | / | Vertical, water-cooled, four-stroke | |
| Qty of cylinders | Cylinder | 6 | |
| Rated power | HP/KW | 120HP/88.3KW | |
| Rated speed | r/min | 2200 | |
| Gearbox | / | TDF16+8 | |
| Gear shift type | / | shift sleeve | |
| Steering | Steering type | / | Full hydraulic steering |
| Brake | Brake type | / | Hydraulic brake, wet type, disc type |
| Walking device | Tire size (front/rear) | / | 12.4-24/16.9-34 |
| Working device | Suspension device type | / | Rear, 3-point suspension, type 2 |
| Suspension device category | / | Category II | |
| Tillage Depth Adjustment | / | Height adjustment, float control | |
| Hydraulic output device | Group | 2 | |
| Standard PTO speed | r/min | keys540/1000 | |
Product advantages
Powerful Engine: Powered by a YTO YTN3 four-cylinder Euro 2 engine with 88.3kW (120hp), no urea needed. It delivers strong torque and low fuel consumption.
Solid Chassis: Built with a reinforced heavy-duty chassis, TDF16+8 helical gear transmission (24+8 optional), and 12-inch independent dual-action clutch. The front axle works well in both paddy and dry fields, with an infinitely adjustable rear track and large 12.4-24/16.9-34 tires for better performance in tough field conditions.
Hydraulics and Control: Equipped with dual high-pressure lift system and two sets of hydraulic outputs, making implement mounting simple and efficient. It features a flat floor layout, hydraulic power steering, and a sealed air-conditioned cab for a comfortable operating environment.
Durable Features: Thickened drive shaft, front and rear counterweights (400kg front, 160kg rear), and an operating weight of about 4.5 tons, making the tractor stable and reliable for long hours of heavy-duty work.
